Permanent Magnetic Iron Remover RCYB-8

Mainly used for typesetting, transportation and storage of green bricks. When the speed of the extruder is unstable, the tilting belt conveyor can achieve the effect of storing the green bricks, thereby ensuring the normal operation of the subsequent grouping, and also can be typeset by the tilting belt conveyor to achieve the number of mud column required for the grouping.

Suitable for the width of belt:	800MM
Height of lifting:	250MM
Thickness:	230mm
Magnetic field intensity :	70MT
Suitable for the speed of belt:	≤2.5m/s
Overall dimension :	700x450x230mm
Weight:	260kg
Availability:

Quantity:



Inquire Add to Basket

Model:
RCYB-8
Brand:
Xiechuang. Bricebt

Permanent Magnetic Iron Remover RCYB-8

Equipment	Permanent Magnetic Iron Remover
Function description	The iron block mixed in the raw material is effectively adsorbed by the high-strength magnetic field of the iron remover, thereby preventing damage to subsequent roller crusher, mixer, extruder, and etc.
Unit type	RCYB-8
Parameter	Suitable for the width of belt	mm	800
	Height of lifting	H=mm	≤250
	Thickness	mm	≤230
	Magnetic field intensity	mT	70
	Suitable for the speed of belt	m/s	≤2.5
	Overall dimension	mm	700x450x230
	Weight	kg	260
